Hot Finished CHS Pipe in Mumbai, Hot Finish Circular Tube, Carbon Steel Hot Finish Circular Hollow Section, Hot Formed Structural Circular Section, Hot Finish Round Pipes, Hot Finish Round Tubing Suppliers.
Hot Finish Mild Steel Circular Hollow Section Exporters, Hot Finished Circular Pipe, BS EN 10210 Hot Rolled CHS Tubes Distributors in India.
Hot Finished Structural Hollow Circular Section, Hot Formed ERW CHS Pipes Stockists, Hot Finish Welded Circular Section Tubes, Seamless Hot Finish Circular Hollow Tubing in Mumbai, India.
Table of Content
Od – Outside diameter
Wt – Wall thickness
Kg/m – Kilos per linear metre
L – Standard bar length
If you are looking for hollow sections at lower cost and high features than hot finish or hot formed circular hollow section is mostly used for structural and mechanical applications and is suitable for your need. This hot form hollow section is easier to bend as compared to cold formed hollow sections. These hollow sections are used in designing of curved frames. These hot finished hollow sections products offer lighter, stronger and more amazing solutions combined with other enhanced aesthetic appeal.
The size of these hollow section pipes and tubes varies from 21.3mm and 508 mm. The thickness lies from 2.5mm to 20mm in the larger sections. The available grades of these hot form sections are S355J2H. There are many companies are avail online which offers hot finish circular hollow sections at standard lengths or they can cut length as according to your order. These hot finished hollow sections are designed mainly from fine grain steel for better performance. The product has yield strength 355 N/mm2 and allows higher fabrication factors and has lighter structure and it is cost saving material to invest in your any kind of structural and constructional projects.
The strength and weldable quality is good and is fully stress relieved with uniform mechanical properties. These hollow section pipes and tubes are used for critical applications where failure simply is not an option. This hot formed circular pipe is suitable for low-temperature applications and is the fully certified product. These are the few features and benefits of circular hollow section pipes.
Hot Finish Circular Hollow Section Specification
Standard : BS EN 10210 - Hot Finished Structural Hollow Sections of Non-alloy and Fine Grain Steels
Sizes : 300 mm NB
Outer Diameter : 21.3 to 457.2mm
Wall Thickness : 1.8mm to 14.27mm
Length : 6000 to 12000/18000mm
Type : Seamless/ Welded / ERW
Dimensional Tolerances : Thickness : (All sizes +/- 10%)
Packing : In bundles, Anticorrosion heat preservation, Varnish coating, Ends can be bevelled or circular cut, End Capped Certification & supplementary test, Finishing & Identity Mark
Available Grades : S235JRH, S275J0H, S275J2H, S355J0H, S355J2H, S355J2+N, IS 4923 / ASTM A500 / As Per Requirement
Surface Protection: Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized
Hot Finish Circular Hollow Section Sizes
| Nominal Bore | Outside diameter | Thickness | Weight |
| mm | mm | mm | kg/m |
| 15 | 21.3 | 2.00 | 0.95 |
| 2.60 | 1.21 | ||
| 3.20 | 1.44 | ||
| 20 | 26.9 | 2.30 | 1.38 |
| 2.60 | 1.56 | ||
| 3.20 | 1.87 | ||
| 25 | 33.7 | 2.60 | 1.98 |
| 3.20 | 0.24 | ||
| 4.00 | 2.93 | ||
| 32 | 42.4 | 2.60 | 2.54 |
| 3.20 | 3.01 | ||
| 4.00 | 3.79 | ||
| 40 | 48.3 | 2.90 | 3.23 |
| 3.20 | 3.56 | ||
| 4.00 | 4.37 | ||
| 50 | 60.3 | 2.90 | 4.08 |
| 3.60 | 5.03 | ||
| 5.00 | 6.19 | ||
| 65 | 76.1 | 3.20 | 5.71 |
| 3.60 | 6.42 | ||
| 4.50 | 7.93 | ||
| 80 | 88.9 | 3.20 | 6.72 |
| 4.00 | 8.36 | ||
| 4.80 | 9.90 | ||
| 100 | 114.3 | 3.60 | 9.75 |
| 4.50 | 12.20 | ||
| 5.40 | 14.50 | ||
| 125 | 139.7 | 4.50 | 15.00 |
| 4.80 | 15.90 | ||
| 5.40 | 17.90 | ||
| 150 | 165.1 | 4.50 | 17.80 |
| 4.80 | 18.90 | ||
| 5.40 | 21.30 | ||
| 150 | 168.3 | 5.00 | 20.1 |
| 6.3 | 25.2 | ||
| 8.00 | 31.6 | ||
| 10.00 | 39 | ||
| 12.5 | 48 | ||
| 200 | 219.1 | 4.80 | 25.38 |
| 6.00 | 31.51 | ||
| 8.00 | 41.67 | ||
| 10.00 | 51.59 | ||
| 250 | 273 | 6.00 | 39.51 |
| 8.00 | 52.30 | ||
| 10.00 | 64.59 | ||
| 300 | 323.9 | 6.30 | 49.36 |
| 8.00 | 62.35 | ||
| 10.00 | 77.44 |
